Ambay Flush Door is IS2202 part1 1999 certified and It is made up of premium quality wood species as specified by IS standards, treated with appropriate Chemicals for protection against termites, borers & other internal & external insect attacks. Bonded with BWP grade phenol formaldehyde synthetic resin to withstand wet & dry conditions.
Its sizes are:-
As per requirement
Its thickness(mm)is:-
25, 30, 32, 35, 38, 40.
| PROPERTIES | SPECIFIED AS PER IS:2202 | CONFORM |
|---|---|---|
| Adhesive used for bonding | As per IS 848:2006 |  |
| Preservative treatment for timber | As per IS 401:2001 | |
| Length of flush door(tolerance) | +6mm,-0mm | |
| Width of flush door(tolerance) | +3mm, -0mm | |
| Thickness(tolerance) | + - 1 mm | |
| Variation in thickness | <0.8mm | |
| General flatness test | not exceed 6mm | |
| Local planeness test | less than 0.5mm | |
| Impact indentation test | less than 0.2mm | |
| Flexure test: | ||
| • Deflection at maximum load | as per IS:4020(part6) | |
| • Residual deflection | as per IS:4020(part6) | |
| Edge loading test: | ||
| Deflection at maximum load(max) | 5mm | |
| • Residual deflection (max) | 0.5mm | |
| • Shock resistance test | As per IS:4020(part8) | |
| Buchling test: | ||
| • Initial deflection(max) | 50mm | |
| • Residual deflection(max) | 5mm | |
| • Slamming test | As per IS:4020(part10) | |
| • Misuse test | As per IS:4020(part11) | |
| • Varying humidity test | As per IS:4020(part12) | |
| • End immersion test | As per IS:4020(part13) | |
| • Knife test | As per IS:4020(part14) | |
| • Glue adhesion test | As per IS:4020(part15) | |
| • Screw withdrawal test | >1000N | |
