The gold plywood is IS710 certified and made with premium quality wood procured from the international markets, treated with the appropriate preservatives for complete protection against wood borers Termite, beetles & fungus. It is bonded with marine grade phenol formaldehyde synthetic resin to survive extreme rigourous wet and dry conditions.
It is used in all types of furniture, doors & windows, construction, marine & river crafts, all types of maintenance and repair purpose.
Its sizes(mts) are as follows:-
2.44x1.22, 2.44x0.92, 2.14x1.22, 2.14x0.92, 1.84x1.22, 1.84x0.92
Its thickness(mm) is as follows:-
3 , 4 , 6 , 9 12, 16, 19, 25
| PROPERTIES | SPECIFIED AS PER IS:710 | CONFORM |
|---|---|---|
| Adhesive used for bonding | As per IS848:2006 |  |
| Preservative treatment for plywood | As per IS10013(parts 1 to 3):1981 | |
| Length of plywood(tolerance) | +6mm,-0mm | |
| Width of plywood(tolerance) | +3mm, -0mm | |
| Thickness(tolerance) | ||
| 1) Less than 6mm | + - 10 percent | |
| 2) 6mm and above | + - 5 percent | |
| Edge straightness (MAX) | 0.2% | |
| Squareness(MAX) | 0.2% | |
| Moisture content(%) | 5-15 | |
| Glue shear strength in dry state :avg | >1350 N | |
| Minimum Individual | >1100 N | |
| • Static bending strength: | >Along the grain(N/MM)2 | |
| • MOE: Avg | >7500 | |
| • Minimum Individual | >6700 | |
| • MOR: Avg | >50 | |
| • Minimum Individual | >45 | |
| Static bending strength: | Along the grain(N/MM)2 | |
| • MOE: Avg | 4000 | |
| • Minimum Individual | 3600 | |
| • MOR: Avg | 30 | |
| • Minimum Individual | 27 | |
| Water Resistance | ||
| o Avg | >1000N | |
| o Minimum Individual | >800N | |
| Retention of preservative | ||
| • Chemical(min) | >12kg/m3 | |
| • Tensile strength: (N/MM)2 | ||
| • Along the grain | >42 | |
| • Across the grain | >25 | |
| • Sum of strength | >84.5 | |
