The platinum plywood is IS710 certified and its a lifetime warranty plywood made with 100% virgin gurjan wood species procured from the deep forests of South East Asian countries .
Each of its veneer layers are treated with boric borax solution for complete protection against wood borers, termites, beetles and fungus, bonded with high quality marine grade phenol formaldehyde synthetic resin to survive extreme rigourous wet & dry conditions.
It is used in all types of furniture, doors & windows, construction, marine & river crafts, all types of maintenance and repair purpose.
Its sizes (in mts.) are as follows:-
2.44x1.22, 2.44x0.92, 2.14x1.22, 2.14x0.92, 1.84x1.22, 1.84x0.92
Its thickness(in mm) is as follows:-
3, 4, 6, 9, 12, 16 ,19, 25
| PROPERTIES | SPECIFIED AS PER IS:710 | CONFORM |
|---|---|---|
| Adhesive used for bonding | As per IS848:2006 |  |
| Preservative treatment for plywood | As per IS10013(parts 1 to 3):1981 | |
| Length of plywood(tolerance) | +6mm,-0mm | |
| Width of plywood(tolerance) | +3mm, -0mm | |
| Thickness(tolerance) | ||
| 1) Less than 6mm | + - 10 percent | |
| 2) 6mm and above | + - 5 percent | |
| Edge straightness (MAX) | 0.2% | |
| Squareness(MAX) | 0.2% | |
| Moisture content(%) | 5-15 | |
| Moisture content(%) | >1350 N | |
| Individual | >1100 N | |
| Static bending strength: | Along the grain(N/MM)2 | |
| • MOE: Avg | >7500 | |
| • Minimum Individual | >6700 | |
| • MOR: Avg | >50 | |
| • Minimum Individual | >45 | |
| Static bending strength | >Across the grain(N/MM)2 | |
| • MOE: Avg | >4000 | |
| • Minimum Individual | >3600 | |
| • MOR:Avg | >30 | |
| • Minimum Individual | >27 | |
| Water Resistance | ||
| o Avg | >1000N | |
| o Minimum Individual | >800N | |
| Retention of preservative | ||
| • Chemical(min) | >12kg/m3 | |
| Tensile strength: (N/MM)2 | ||
| • Along the grain | >42 | |
| • Across the grain | >25 | |
| • Sum of strength | >84.5 | |
